This product is a precision electronic component designed specifically for circuit board connections that require high reliability and stability. This product adopts IDC (Insulation Displacement Connection) female sockets with a spacing of 1.27mm, and the color is eye-catching red, which is easy to quickly identify and install on the circuit board. By using SMT (Surface Mount Technology) to achieve a tight connection with the circuit board, the stability and durability of the connection are ensured.
Product Name | Red board end female seat without ear or table SMT |
Colloidal material | PA6T |
Iron shell material | nothing |
Terminal material | bronze |
Iron shell electroplating | High temperature bright tin |
Maximum withstand voltage | 500V |
Insulation resistance | ≥20MΩ |
Contact resistance | ≤20mΩ |
This connector is widely used in various fields such as electronics, communication, computers, automobiles, medical equipment, etc. Specifically, it can be used for:
Circuit board connection: serves as a bridge between the circuit board and other components or modules, achieving stable signal transmission.
Internal interconnection of devices: Used within complex electronic devices to interconnect modules and improve overall system performance.
Automated production line: As a key component of signal transmission in the automation control system, it ensures the stable operation of the system.
Stable transmission: Provide reliable electrical connections to ensure stable and lossless transmission of signals within circuit boards or equipment.
Easy to install: Adopting SMT technology simplifies the installation process and reduces labor costs.
High durability: High quality materials and structural design ensure the long-term reliability of the connector in harsh environments.
Flexible design: supports customization of different pin numbers and row numbers to meet the needs of different application scenarios.
Safe and reliable: Complies with relevant international safety and quality certification standards, providing users with security assurance.
Efficient heat dissipation: Good heat dissipation performance helps to reduce the operating temperature of connectors and circuit boards, extending their service life.
Clear identification: The eye-catching red appearance facilitates quick recognition and positioning on complex circuit boards.
Strong adaptability: able to adapt to work requirements under different environmental conditions, such as changes in temperature, humidity, etc.
Easy to maintain: The replacement and repair process is simple and fast, reducing equipment downtime and maintenance costs.
Environmental protection and energy conservation: Made with environmentally friendly materials, it meets the requirements of green production and also helps to reduce energy consumption.
