Linear guide slider QR series: high-speed performance and high-precision processing capability

The pictures, models, parameters and other relevant information displayed in the product are for reference only. If you are searching for products related to fields such as electronic components, precision components, office automation, and factory automation, or if you need customized products in this field. Welcome to contact us through the consultation form, telephone or any way you find convenient. We will reply to you as soon as possible. We always adhere to the purpose of striving for the best to provide you with the highest quality service. We look forward to establishing a friendly and stable cooperative relationship with you.

Product Description:

Linear guide QRW30CC has ultra-high rigidity in all directions. The QR series linear guide not only improves high-speed performance by installing a patented synchronous coupling, but also replaces the ball with a roller type rolling element. Through the linear contact between the roller, guide rail, and slider, the elastic deformation of the roller under load is effectively reduced. This not only greatly improves the rigidity of the linear guide, but also maintains high-precision machining at high speeds.

Self lubricating design without adding oil

The synchronous coupling of the patent is designed with an oil storage space in the middle interval, which can supply the lubrication needs of the steel ball during operation. When passing through the directional rotating part, the lubricating oil can be evenly replenished in the oil storage space, continuing to evenly lubricate the steel ball. Therefore, the frequency of supplementing lubricating oil can be effectively reduced.

Improve smoothness of movement

When traditional linear guides without synchronous couplings start running, the steel balls on the load side will move first, and then push the rotating part in the direction to collide with the steel balls on the unloaded side, causing a chain reaction of back and forth collisions, resulting in significant fluctuations in frictional resistance. The QH series linear guide rail using SynchMotionTM technology has a synchronous coupling that connects all the steel balls in the same cycle together. Therefore, when the slider starts moving, all the steel balls start almost simultaneously, and there is no back and forth collision between the steel balls. While maintaining a certain degree of motion inertia, the fluctuation amplitude of frictional resistance can be effectively reduced.

High speed design

The spacing design of the synchronous coupler can eliminate the mutual friction between the balls, and HIWIN's patented design enables a circular line contact between the balls and the synchronous coupler, effectively reducing frictional resistance and enabling the silent linear guide to have excellent high-speed performance.

Technical Parameter:

customization:

QR slider type:The QR series offers two types of linear guides: flange type and square type. The flange type slider has machined installation screw holes at the flange for installation, and is also suitable for the installation of the lower lock. Its linear guide combination has a low height and a large bearing area, making it suitable for fields that can withstand distance loads. The square slider has a smaller width and is suitable for devices with limited installation space. The screw holes above the slider can be used for installation.

Guideways Type:In addition to the general locking bolt hole guide rail, the QR series also offers a lower locking bolt hole guide rail for easy installation and use by customers.

Accuracy class:The precision of the QR series linear guide is divided into four levels: high H level, precision P level, ultra precision SP level, and ultra high precision UP level. Customers can choose the precision according to their equipment precision requirements.
