Linear guide SGW series: high load capacity, long lifespan, large torque allowance, and smooth movement

The pictures, models, parameters and other relevant information displayed in the product are for reference only. If you are searching for products related to fields such as electronic components, precision components, office automation, and factory automation, or if you need customized products in this field. Welcome to contact us through the consultation form, telephone or any way you find convenient. We will reply to you as soon as possible. We always adhere to the purpose of striving for the best to provide you with the highest quality service. We look forward to establishing a friendly and stable cooperative relationship with you.

Product Description:

This product showcases significant competitive advantages in the market with its outstanding performance and diverse characteristics. While it can provide solutions for high load capacity and long lifespan, it also excels in aspects such as torque resistance, balanced load in four directions, smooth movement, corrosion resistance, dustproofing, and lubrication. Whether in industrial production, scientific research experiments, or other fields, this product can bring efficient and reliable usage experiences to users and is an ideal choice for numerous application scenarios.

Technical Parameter:

Applicable scenarios:

With many excellent characteristics such as high load capacity, long lifespan, allowance for large torque, balanced load in four directions, smooth movement, corrosion resistance, dustproofing, and fiber cardboard, this product is widely used in many fields.

In the field of industrial automation, it can be used in production line conveyor systems, robot joints and other parts to meet the needs of high load, high precision and long lifespan. In the field of precision instrument manufacturing, its smooth movement characteristics and corrosion resistance specifications make it an ideal choice for moving parts such as microscopes and measuring equipment. In clean room environments such as electronic chip manufacturing and pharmaceutical production industries, the standardized LB specification and good dustproof performance ensure a clean and stable production process. In addition, in some special equipment that requires high torque transmission and precise linear movement, this product can also play an important role.

Product Function:

Combining high load capacity and long lifespan: The conveying surface of the product is in an R shape approximating the radius of a steel ball, cleverly increasing the contact area between steel balls. The increased contact area endows the product with strong pressure and load-bearing capacity, enabling high-load operation. At the same time, the optimized contact method effectively reduces wear between steel balls and significantly extends the service life of the product, bringing users a long-term and stable usage experience.

Outstanding torque resistance: The wide design results in excellent torque resistance, making it perform extraordinarily in work scenarios with large torques and being able to handle single-axis use easily. Whether in heavy machinery transmission systems or equipment requiring precise torque control, this product can play a key role.

Balanced and stable load in four directions: Steel balls are evenly arranged at a 45-degree angle, ensuring that the product has the same load capacity in all four directions: up, down, left, and right. This balanced load distribution makes the equipment stable in performance in all directions and not affected by the direction of force. Whether in horizontal linear movement or vertical load-bearing tasks, the product can play a reliable role.

Smooth movement, precise and reliable: Many steel balls work together to bring extremely smooth linear movement to the product. When steel balls roll on the track, they evenly share the load and reduce vibration and shaking. For equipment requiring high-precision positioning and motion control, such as precision instruments and automated production lines, this characteristic is crucial. It can improve the working accuracy of the equipment, reduce errors, and ensure the stability and reliability of the production process.

Corrosion resistance specifications with wide adaptability: The track and slider are treated with low-temperature black chrome, greatly improving the corrosion resistance of the product. The treated surface can effectively resist erosion by corrosion factors such as moisture and chemicals. The standardization of the LB specification makes it particularly suitable for places with high environmental requirements such as clean rooms. In these environments, the product can maintain good performance and appearance without being affected by corrosion in service life and work efficiency.

Tight and effective dustproof measures: The standardized loading of the side sealing ring provides the first line of dustproof defense for the product, effectively preventing dust and impurities from entering the interior and protecting steel balls and tracks from pollution. In addition, bottom sealing rings and dedicated covers are available for selection and can be used in combination according to different working environments and needs to ensure that the product can operate well even under harsh working conditions.

Innovative lubrication with fiber cardboard: The slider body can be equipped with fiber cardboard containing lubricating grease, providing convenience for product lubrication. Fiber cardboard can supply an appropriate amount of lubricating grease to the conveying groove, greatly extending the oil injection interval. This not only reduces the frequency of maintenance, lowers the use cost, but also improves the reliability and stability of the product. During long-term use, fiber cardboard continuously provides lubrication for steel balls and tracks, reducing wear and extending the service life of the product.
